Debugging a Hexagonal CSS Masonry Layout

Before CSS will eventually get an official masonry layout with or without grid, we can achieve something similar with flex and some scripting, provided that all bricks (or tiles) have the same size. Then we can move every second row towards the top right to fill the gaps between the spikes of the previous elements.

A Seemingly Simple Styling Idea

Now, that’s another seemingly simple use case that nobody seemed to care about before, probably for similar reasons as with parallax scrolling beyond landscape images, is a simplified masonry layout where all items have the same size and a hexagonal shape like tiles in a world-building game.

I initially thought that this could be a use case for CSS Grid, and I tried to figure out how to combine grid’s auto-flow, auto-fill (or auto-fit?) with min-content to achieve a flex-like auto-wrapping behavior.

I gave up as I saw that flex is still a simpler solution and grid didn’t have what I thought it had: an option to style items depending on which row they were auto-placed in.

I almost gave up on my silly use case, but I was rewarded by the kind of errors only possible in visual frontend development, so let me take you on my journey of mathematical misconceptions step by step towards the following result.

That’s how it looks in my demo at dev-ux-lesezeichen.de now.

Let’s recap my steps and how not to do it.

Polyfilling Auto-Placement Row Detection

We can let the browser auto-place items in columns and wrap them to new rows in a responsive way, but neither flex nor grid will tell us the row that an individual item has been placed into.

Minding the Gaps

We don’t need a rocket science degree to do the maths:

row 1: top 0 = 0 * (height + gap)
row 2: top 1 * height + 1 * gap = 1 * (height + gap)
row 3: top 2 * height + 2 * gap = 2 * (height + gap)

The gap is a property of the flex or grid container.

const verticalGap = getComputedStyle(layoutContainer).rowGap;

All tiles have the same height, so we can query any tile just once (or use the expected height that we set in CSS). Adding height and gap, we know the inclusive height of one row.

let gappedHeight = firstTile.offsetHeight + verticalGap;

The container must be positioned, so we can use offsetTop to measure the distance of each item’s top to the parent’s top.

We can detect which rows are odd (e.g. 1, 3, 5, …) or even (2, 4, 6, …) just like in nth-child(odd) (and remember that CSS counts uses ordinal numbers starting from 1, not 0, so the first row will be an odd row number one.

This must be done for every item, and rerun after the window has been resized or a device was rotated.

const wrappableElements = layoutContainer.children;
for (const wrappableElement of wrappableElements) {
  const tileElement = wrappableElement as HTMLElement;
  let offsetRows = Math.floor(tileElement.offsetTop / gappedHeight);
  tileElement.classList.add((offsetRows % 2) ? 'is-even' : 'is-odd');

I thought that Math.floor just eliminates possible sub-pixel anomalies, but it maybe it just hides a more fundamental problem. We will see in the debugging section below.

Hexagonal Masonry Layout in Practice, Work in Progress

Some screenshots from experiment to proof of concept:

An early app preview reminded me of a sketch of an hourglass, before I ensured all items are equally sized and clip their content if it’s too long.

Another intermediate situation, appropriately with the book “Debugging CSS” at the centre of my screen.

Eventually, the first two rows were correct, but not the third one.

Debugging

We could write our intermediate calculation steps into class anmes or data attributes to see them at each item, making debugging more visual than just logging to the console.

tileElement.dataset.offsetTop = String(tileElement.offsetTop);

Rounded rows vs. raw interim values

In an ideal world (or window), there would be only integer values here, like class="row-2".


  data-gapped-height="436"
  data-offset-top="783"
  data-offset-rows="1"
  class="row-2 is-even">

Inspecting raw values before applying Math.floor, we can see a growing discrepancy in an unexpected direction. While the second row plus gap is 1 pixel higher than expected, the third row is 89 pixels above its expected position.

let offsetRows = Math.floor(tileElement.offsetTop / gappedHeight);

row 1: offsetTop 0 / 436 = 0
row 2: offsetTop 437 / 436 = 1.002293578
row 3: offsetTop 783 / 436 = 1.79587156 (436 *2 = 872)

That’s got nothing to do with the heights. Those are still equal, as we can see with our eyes and verify in our dev tools.

However, moving the tiles towards the top without compensating by a bottom margin is what messed up my plans.

.custom-grid-has-row-behavior .is-even {
    margin: -6rem -10rem 1rem 10rem;

The provisional margin-bottom: 1rem should have been 6rem to compensate the top -6rem shift? That still doesn’t look correct.

Now the rows are detected consistently, although I’d expect that to fail given the unexpected extra spacing.

row 1: offsetTop 0 / 436 = 0
row 2: offsetTop 437 / 436 = 1.002293578
row 3: offsetTop 873 / 436 = 2.002293578 (436 *2 = 872)
row 4: offsetTop 1310 / 436 = 3.004587156
row 5: offsetTop 1746/ 436 = 4.004587156

The slightly growing offset won’t break our layout before adding up to a mathematical extra row number 436, which will never happen™.

Removing the Gaps

What if we simplify things and eliminate unpredictable gapping by setting the flex/grid gap to zero and adding a padding inside our list items wrapping the visible tiles? (Actually, it’s even a little bit more complicated, as each of my flex children wraps not one, but two tiles, but let’s just notice that we’ve already got a wrapper that we can pad instead of the flex gap.)

Then we can also remove our compensation margin at the bottom.

.custom-grid-has-row-behavior .is-even {
    margin: -6rem -10rem 0 10rem;

and fix the failing third row detection.

row 1: offsetTop 0 / 437 = 0
row 2: offsetTop 437 / 437 = 1
row 3: offsetTop 765 / 437 = 1.750572082

437 * 2 = 847
847 – 765 = 109
109px = 6.8125rem = 6rem + 13px = 🤔?

Instead of the row gap, we must account for the omitted 6rem bottom padding in our calculation, but that only happens every second row.

I made a misconception when I said we only move every second row to the top. We must move every row but the first! Then, at least, we have a different kind of error. That’s what I love about visual debugging: even when it’s broken, it looks cool! 😂

.custom-grid-has-row-behavior *:not(:first-child) {
  margin-top: -6rem;

That should have been “not first row”, not “not first child”. Detecting rows beyond CSS’ native pseudo-selectors was the whole point of doing custom JS calculations.

.custom-grid-has-row-behavior *:not(.row-1) {
  margin-top: -6rem;

Relying on my custom class names applies the margins after my calculation, but I need them before. That’s a problem I already had from the beginning. That could possibly also simplify my calculations. If extra top margins don’t matter, then why would we need to consider them at all?

But the point is: all items don’t have a .row-1 class before the script ran, so my “fix” gives every item a negative top margin. So let’s fix this. Instead of an overengineered [class^="row"]:not(.row-1) let’s just add two classes each, like row and row-1 and write CSS that’s easy to read:

.custom-grid-has-row-behavior .row:not(.row-1) {
  margin-top: -6rem;

Let’s look at the third row that’s still not correctly detected.

row 3: offsetTop 873 / 437 = 1.99771167

Math.floor(tileElement.offsetTop / gappedHeight) as a recipe for disaster?

Overengineered or Off by One Pixel?

Pragmatically, I could change Math.floor() to Math.round(), as we have only one pixel difference to our expected values. “Pixel imperfections happen,” I thought, “and they happen inconsistently across different browser engines and screen sizes. If you still feel that rounding is a too dirty solution, I’m curious to find your better solution in the comments!”

Honestly, my fix fixed the first four rows but failed to detect the fifth, and I only noticed after I had removed the debug properties. Obviously, there’s more than just an “off-by-one-pixel” issue. A narrower screen makes it more obvious and show the error on line 3 already.

row 2: offsetHeight 765 / 437 = 1.7505720823798627-> 2
row 3: offsetHeight 1094 / 437 = 2.5034324942791764-> 3
row 4: offsetHeight 1422 / 437 = 3.254004576659039-> 3

Row three and four are both treated as row three, breaking the even-odd-layout, and row 2 is already off by 109 pixels (6.8125rem) again, or 437 should be 382.5? Proceeding to find a pattern:

row 2: 2*437 = 874 (-109) (765/2 = 382.5)
row 3: 3*437 = 1311 (-217) (1094/3 = 364.666666667)
row 4: 4*437 = 1748 (-326) (1422/4 = 355.5)

Can you see the pattern? I can’t!

Calculating, Sorting, or Comparing?

Searching the web for alternative solutions, I came across the idea of sorting unique offsets instead of dividing and rounding. Looking up the array or set index for any element’s top offset is my new row number (minus one).

Does this still look overengineered? It does!

What if there was a much simpler and more robust solution?

What if I just compare each top offset to the previous element’s and increase a row counter when they differ?

for (const tileElement of tileElements) {
    if (tileElement.offsetTop > previousOffset) {
        currentRow++;
      }
    previousOffset = tileElement.offsetTop;

Why didn’t I think of this simple solution much earlier?

Edge Case Testing

Let’s not forget about testing edge cases by creating variations and exaggerating problems like unusually long names or arabic content that implicitly behaves like a span with a changed writing direction.

Here is a fictitious book by Hubert Blaine Wolfeschlegelsteinhausenbergerdorff about things to do in Llanfairpwllgwyngyllgogerychwyrndrobwllllantysiliogogogoch. I didn’t make up either, and I prefer them to repetitive Lorem Ipsum by Jane Doe examples that only test the so-called “happy path”.

Resizing a window or rotating a mobile phone is another case often overlooked by web designers and developers. My initial placement function would only work once, as the counting calculation depends on the intial auto-placed element positions.

Here’s my final logic:

const refineMasonryLayout = // placement function
export const refineAllMasonryLayouts = (): void => {
  // find and reset all modified elements:
  let adjustedGridChildren = document.getElementsByClassName('custom-shifted');
  for (let adjusted of adjustedGridChildren) {
    adjusted.classList.remove('custom-shifted');
  }
  // then do the actual placement ...
}

addEventListener('DOMContentLoaded', () => {
  refineAllMasonryLayouts()
})

addEventListener('resize', () => {
  refineAllMasonryLayouts();
})

I call the placement functions after initial rendering, after resizing, and I export it so that I can call it after a React wrapper might have rerendered.

Software Architecture

Last but not least, where does this code belong in a project? After I reopened my Astro/React side project after some time, I’d expect it somewhere in or called by Layout.astro or in a TypeScript file called something with placement, but it turned out I had named it refineMasonryLayout.ts in a utils folder.

I decided to publish the code as an npm module so I can refine the code and concept in one central place to avoid further confusion and possible inconsistent states of duplicated code across projects, if I ever use it anywhere else.

Debugging Again

Creating a minimal reproducible example on codepen, simplified without wrapped pairs, and scoping my functions to a module that you can import from npm, meant debugging again, creating more unexpected decorative patterns on my way to the expected layout.

Here is the current codepen (Hexagonal Masonry Layout)

The point that I missed was my original example didn’t just use wrappers to group pairs of tiles but also used padding for inner spacing. Trying to use arbitrary margin outside the tiles will break the layout algorithm. A new simplified proof of concept puts a white 2-pixel border plus a 2-pixel bottom margin.

<br />

You can experiment with you own settings and have a look at dev-UX-Lesezeichen.de.
